Spec
| Brand | TOTOLINK |
| Model | A3100R |
| Standards | IEEE 802.11ac n/g/b/a |
| Frequency Range | 2.4GHz/5GHz |
| WiFi Speed | AC1200 |
| Data Rate | – 2.4GHz: Up to 300Mbps – 5GHz: Up to 867Mbps |
| EIRP | – 2.4GHz < 20dBm – 5GHz < 20dBm |
| Reception Sensitivity | – 2.4G: 11b 11M：-81dBm@8% PER 11g 54M：-68dBm@10% PER 11n HT20 MCS7：-65dBm@10% PER HT40 MCS7：-62dBm@10% PER- 5G: 11a 54M：-68dBm@10% PER 11ac: HT20<-65dbm HT40 MCS7：-62dBm@10% PER 11ac VHT80 MCS9：-51dBm@10% PER |
| Interface | – 2 *1000Mbps LAN Ports – 1 *1000Mbps WAN Port |
| Operation Mode | – Gateway Mode – Bridge Mode – Repeater Mode – WISP Mode |
| Wireless Security | 64/128-bit WEP, WPA and WPA2 |
| Wireless Mode | Multiple SSIDs, MAC Authentication, WDS, WPS, IPV6,IPTV |
| Antenna | 3 *5dBi fixed antennas (2.4G),2 *5dBi fixed antennas (5G) |
| Dimensions | 7.5 x 5.2 x 1.4 in. ( 190 x 131 x 36mm) |
| Power Supply Unit | 9V DC / 0.8A |
| LEDs | 1 * SYSTEM |
| Firewall | MAC Filtering, IP Filtering, Port Filtering, URL Filtering Port Forwarding, DMZ |
| Management | QoS, DDNS, Remote management, etc |
| Package Contents | – 1 *A3100R Wireless Router – 1 *Power Adapter – 1 *Ethernet Cable – 1 *Quick Installation Guide |
